The following are common uses of Huawei HS8546V5:
Basic settings
Log in to the optical modem: After connecting to the optical modem via wired or wireless means, enter the IP address of the optical modem in the browser address bar, usually 192.168.1.1, and then enter the account and password to log in to its Web configuration interface. The account and password are usually marked on the nameplate on the back of the optical modem.
Modify Wi-Fi password: After logging in to the Web interface, select "Network > WLAN Network Configuration > 2.4G/5G WLAN Basic Parameter Configuration" page, click "Show Password", enter the new password and click "OK".
Network configuration
Set bridge mode: In bridge mode, the optical modem only acts as a photoelectric conversion device, and the router dials up to the Internet. Different operators have slightly different settings. Take China Mobile as an example. Log in to the management interface of the optical modem, find the "Broadband Settings" option under the "Network" menu, find the corresponding Internet connection in the connection name, which is usually "INTERNET_R_VID_41" or similar names, change its mode from "Routing" to "Bridging", and save the settings.
Port binding and VLAN configuration: If you need to achieve special network requirements such as single-line multiplexing, you need to bind the optical modem's port to VLAN. For example, a certain network port can be bound to a specific VLAN ID for IPTV services, and another network port can be bound to a VLAN ID for Internet services, so as to achieve the transmission of multiple services on one network cable.
Use of storage function
HS8546V5 has a USB interface, which can be inserted into a storage device such as a USB flash drive. The USB storage device can be managed in the management interface of the optical modem, such as viewing the status of the storage device, formatting, etc. It can be used as a simple home network storage.
Voice function configuration
Register voice service: If the optical modem has a POTS voice interface, you need to apply for voice service from the operator and obtain relevant configuration parameters, and then enter these parameters in the voice configuration interface of the optical modem to complete the registration of voice service.
Set voice function: After configuring the voice service, you can set voice-related functions in the management interface of the optical modem, such as adjusting the ringtone volume, setting call forwarding, etc.
System management
Backup and restore configuration: You can log in to the command line interface of the optical modem through telnet and use commands to back up the configuration file to a storage device such as a USB flash drive so that you can restore the configuration when needed.
Upgrade system software: In the management interface of the optical modem, there is usually a "system upgrade" option, which can be used to check and download the latest system software pushed by the operator to upgrade the optical modem for better performance and function support.
