Huawei GPBD optical access equipment is mainly used for OLT equipment in GPON/EPON systems. It is a small and medium-capacity device with similar functions and effects to Huawei MA5680T12.
Scope of application and functions
Huawei GPBD optical access equipment can be configured with a variety of boards, including business boards, main control boards, uplink interface boards, power boards, etc. The specific functions are as follows:
Business board: such as GPBC and EPBC, providing GPON and EPON access functions respectively.
Main control board: such as SCUL, responsible for system control.
Uplink interface board: such as GICF and X1CA, providing GE and 10GE uplink functions.
Power board: such as PRTE, powering the business box.
Monitoring board: such as PMIA, providing environmental monitoring and network port uplink functions1.
Configuration and interface information
Huawei GPBD provides 13 slots, including 6 service board slots, 2 main control board slots, 2 GIU uplink board slots, 2 power board slots and 1 general interface board slot. The specific configuration is as follows:
Slots 0 to 5: Configure service boards.
Slots 6 to 7: Configure main control boards to achieve master-slave functions.
Slots 8 to 9: Configure GIU uplink boards.
Slots 10 to 11: Configure power boards.
Slots 12: Configure general interface boards1.
Environmental parameters and power supply parameters
Huawei GPBD's environmental parameters include an operating temperature range of -30°C to +60°C, an operating humidity of 5%RH to 95%RH, and an air pressure environment of 54kPa to 106kPa. In terms of power supply parameters, the device requires external power supply1.
