Huawei EchoLife EG8141A5 XPON ONU

ONT/ONU EG8141A5 is a budget proposition that offers all the services needed today. It allows to get stable access to broadband Internet, providing fast data transfers, HD video streaming and VoIP. Intuitive configuration allows to use the device for triple play services - Internet, TV and telephone. Rich management options compatible with current standards allow the ISP to adapt the device to the specific network.

Availability:

Quantity:



Inquire Add to Basket

Model:
EchoLife EG8141A4
Brand:
HUAWEI

Product Description

HUAWEI EG8141A5 APC Optical Network Terminal is equipped with GPON interface and built-in router with 1 Gigabit Ethernet port, 3 Fast Ethernet ports, RJ-11 connector for POTS and WiFi 2.4 GHz.

Huawei EG8141A5 Description:

- The EchoLife EG8141A5, an optical network terminal (ONT), is a high-end home in FTTH solution.

- By using the GPON technology, ultra-broadband access is provided for home and SOHO users.

- The EG8141A5 provides one POTS ports,four FE Internet port.

- The EG8141A5 features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services.

EG8141A5 Specification

Dimensions (H x W x D)	30 mm x 152 mm x 105 mm (without an external antenna and pads)
Operating temperature	0°C to +40°C
Operating humidity	5% RH to 95% RH (non-condensing)
Power adapter input	100–240 V AC, 50/60 Hz
System power supply	11–14 V DC, 1 A
Static power consumption	3.1 W
Max power consumption	7.15 W
NNI	GPON
UNI	1POTS + 1GE + 3FE + 2.4G Wi-Fi
Optical Connector	SC/APC
Indicators	POWER/PON/LOS/LAN/TEL/WLAN/WPS
Installation mode	On the desk, or on the wall
Compliance certification	CE/Wi-Fi
