Huawei HS8145V is a GPON (ONT - Optical Network Terminal) designed as an ideal device for home gateway units (HGU - Home Gateway Unit) to be used in FTTH networks. This gateway supports Layer 3 functionality to facilitate the creation of a smart home network. It also provides the user with access to all Triple-play services (Internet, VoIP telephony, IPTV). Huawei HS8145V has been equipped with 4 Gigabit Ethernet ports , 1 telephone port (1x POTS) and 2x USB ports. HS 8145V has been equipped with a built-in wireless Wi-Fi radio operating in 2.4 and 5 GHz bands simultaneously(dual band). It supports modern AC standard and 2x2 MIMO dualchain technology, the maximum theoretical transmission speed is up to 300 Mbps in 2.4 GHz band and 867 Mbps in 5 GHz band. The device has two external antennas, each with 2 dBi gain. The set includes a DC 12V 1.5A adapter with European plug.
Terminal GPON ONT class B+
Fiber optic connector port GPON SC/ UPC
4 RJ-45 10/100/1000 Mbps Gigabit Ethernet LAN ports
2 x USB
1 POTS phone port (1x POTS RJ11)
Dual-band 2.4 GHz and 5 GHz AC Wi-Fi transmission
Supports modern ac standard and 2x2 mimo dualchain technology
Maximum theoretical throughput is up to 300 Mbps in the 2.4 GHz band and 867 Mbps in the 5 GHz band
| Model | EchoLife EG8145V5 |
| Type | Routing |
| Dimensions (H x W x D) | 30 mm x 155 mm x 105 mm(without external antenna and pads) |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| Power Adapter Input | 100V to 240V AC, 50 Hz/60 Hz |
| System Power Supply | 11V to 14V DC, 2A |
| Network-side Ports | GPON |
| User-side Ports | 1 POTS + 4 GE + Wi-Fi + USB |
| Indicators | POWER, PON, LOS, LAN1, LAN2, LAN3, LAN4, TEL, USB, WLAN, and WPS |
